METTLEAIR

5 Ports 4 Way 3 Position PRESSURE Center Valve 3/8" NPT (Exh. 1/4") Wire Leads Double Solenoid AC 110V

5 Ports 4 Way 3 Position PRESSURE Center Valve 3/8" NPT (Exh. 1/4") Wire Leads Double Solenoid AC 110V

SKU: 4V330P-10-AC110W

Regular price $129.98 CAD
Regular price Sale price $129.98 CAD
Sale Sold out
Shipping calculated at checkout.

Product Features

  • Type: 5 Ports 4 Way 3 Position Double Solenoid Valve Pressure Center Type
  • Model: 4V330P-10-AC110W
  • Coil: 110V AC, Wired Coil
  • Ports: 3/8" NPT
Exhaust: 1/4" NPT

Product Description



Flow Rate (Cv): 1.00

Body Material: Aluminum

Quantity: 1 (One) piece

Positions: Five way/Three position

Effective Section Area: 18mm² (CV=1.00)

Port Size: Air Inlet=Air Outlet=3/8"NPT ; Exhaust=1/4NPT

Working Media: 40 Micron Filtered Air

Motion Pattern: Inner Guide Type

Operating Pressure:22-116 PSI

Operating Temperature:5ºC to 50ºC / 41ºF to 122ºF

Allowable Voltage Fluctuations: ±10% of Rated Voltage

Power Consumption: AC: 5.5 VA/ DC: 4.8W

Insulation and Protection: Class F Class / IP65

Wiring Form: Lead Wire or Connector Type

Highest Action Frequency: 5 Cycles/Second

Shortest Excitation Time: 0.05 Second

This precision product works great with other quality MettleAir accessories.
